Microtek NDT-2000 User Manual

10 NDT-2000 User's Manual
• Easy to operate, clean and maintain — The NDT-2000 requires virtually no
routine maintenance and no daily cleaning, which is ideal for radiographic
inspection industry.
• Auto Scan — The scanner is equipped with a sensor that can automatically
detects if there is lm on the input tray; once the lm is detected, the
scanner starts scanning automatically.
• Optional Auto Film Feeder (AFF) — The AFF can hold up to 15 sheets of
X-ray lms at one time. When an AFF installed, you can easily perform
scanning of multiple lms automatically, making your scanning work more
efciently.
• Optional Multi-channel Film Feeder — This device allows the NDT-2000 to
scan 2-3 sheets of 60 mm, 70 mm, 80 mm, 90 mm, 100 mm, 120 mm,
140 mm, 3.3 inch and 4.5 inch in width lm at one time.
• Microtek ScanWizard Industry software — SanWizard Industry is dedicated
scanning software developed by Microtek for capturing images of industry
X-ray lm. It is easy to install and use.
• Optional Microtek MiiNDT software — MiiNDT is software exclusively
designed for the image management in the RT industry. It can combine
inspecting information and images together and then save them into
DICONDE format meeting with the ASTM standard. Further, users can
search, check, measure, mark, or print out these les for their preferences
conveniently.
System Requirements
In order to use your NDT-2000, your computer must satisfy the following system
requirements:
• CD-ROM/DVD-ROM drive (for installing software)
• Color display with 24-bit color output capability
• 4GB RAM or more
• Pentium IV PC or higher with Hi-Speed USB (USB 2.0) port
• Windows 7 / 10 (64-bit)

Microtek NDT-2000 Specifications

Scanning Specifications

resolution	1200 dpi (21 μm)
optical density	0.37D~ 4.5D
scanning area min	2.5” x 2.5” (63.5 mm x 63.5 mm)
scanning area max	14“ x 200” (355.6 mm x 5080 mm)
scanning speed 3.5D	58 sec @ 300 dpi, 14” x 17” grayscale
scanning speed 4.0D	110 sec @ 300 dpi, 14” x 17” grayscale
scanning speed 4.5D	232 sec @ 300 dpi, 14” x 17” grayscale

Film Specifications

film size min	2.5” x 2.5” (63.5 mm x 63.5 mm)
film size max	14“ x 200” (355.6 mm x 5080 mm)
film holder	8.5” x 4.5”, 12” x 3 1/3”

Power

voltage	AC 100V to 240V, 50/60 Hz
max current	4.0A (Input)
power consumption	Max. 320 W

Operating Environment

operating temperature	50° to 104°F (10° to 40°C)
operating relative humidity	20% to 85%
storage temperature	14° to 140°F (-10° to 60°C)
storage relative humidity	20% to 95%

Weight and Dimensions

dimensions	12.9” x 18.7” x 8.8” (329 x 474 x 224 mm)
dimensions with input tray	329 x 474 x 544 mm
dimensions with input and output tray	586 x 474 x 934 mm
weight	44.5 lbs. (20.2 kg)
