Positioning the X-ray Films
The AFF can hold up to 15 sheets of X-ray lms at a time. This section shows
you how to position X-ray lms into the tray of the AFF correctly.
1. Install the AFF onto your digitizer
before using it. Refer to the
previous sections “Installing and
Connecting the Auto Film Feeder
(AFF)” for the detail.
2. Lift up the Top Bar.
AFF
Top Bar
Rear Rollers
