54 NDT-2000 User's Manual
Scanning X-ray Films by Using the Auto Film Feeder (AFF)
1. Load the lms to be scanned into the tray of the AFF.
Make sure that the Light Shield has been pulled up if the width of the lm is
large than 10.24” (26 cm); otherwise, pull it down.
2. Launch ScanWizard Industry (either as a stand-alone by clicking the program
icon on the desktop, or by using the “File-Import” or “Scan” command from
an application program).
3. Click the Scan Process Tool button and then choose “Auto Film Feeder” from
the appearing drop-down menu.
4. Click the Overview button to perform a preliminary scan of the image, which
will appear in the Preview window.
5. Select your image output type as Gray Scale or Gray Scale (16-bit) from the
Type drop-down menu.
6. Select your desired image output resolution in the Resolution drop-down
menu. The recommended resolution is 300 dpi or above.
7. Select the Scan Frame tool ( ) from the Toolbar in the Preview window, and
choose the area to be scanned by dragging a rectangle around it. You will
see a ashing frame (marquee) around the selected area.
8. Select your desired image quality (3.5D, 4.0D, or 4.5D) from the Density
drop-down menu for the current scan job, based on the needs/image quality
requirements of the inspection.
9. If necessary, select your desired scan mode (Standard Mode or Speed
Mode) from the Scan Mode drop-down menu to scan lm based on the
requirements.
10. Click the Scan button in the Preview window to scan all the lms loaded on
the tray of the AFF.
• If ScanWizard Industry is launched as a stand-alone program, a window
“Scan To: Save As” dialog box will appear. Click the Save button; then,
the scanned image can be saved into your selected folder or sent to your
selected application.
To view the scanned image, double click the “Industry Images” icon on
your desktop (default folder assigned by the software), or retrieve it from
your assigned folder.
• If ScanWizard Industry is launched as a Plug-In from an image-editing
program, the scanned image is delivered to your application, where the
image can be saved, viewed, or modied further.
NOTE: When scanning with the AFF function, the height limit for the scan frame
is 17”. If the value of the height in the scan frame is larger than 17, it will be set
back to 17” automatically by the system.

Microtek NDT-2000 Specifications

Scanning Specifications

resolution	1200 dpi (21 μm)
optical density	0.37D~ 4.5D
scanning area min	2.5” x 2.5” (63.5 mm x 63.5 mm)
scanning area max	14“ x 200” (355.6 mm x 5080 mm)
scanning speed 3.5D	58 sec @ 300 dpi, 14” x 17” grayscale
scanning speed 4.0D	110 sec @ 300 dpi, 14” x 17” grayscale
scanning speed 4.5D	232 sec @ 300 dpi, 14” x 17” grayscale

Film Specifications

film size min	2.5” x 2.5” (63.5 mm x 63.5 mm)
film size max	14“ x 200” (355.6 mm x 5080 mm)
film holder	8.5” x 4.5”, 12” x 3 1/3”

Power

voltage	AC 100V to 240V, 50/60 Hz
max current	4.0A (Input)
power consumption	Max. 320 W

Operating Environment

operating temperature	50° to 104°F (10° to 40°C)
operating relative humidity	20% to 85%
storage temperature	14° to 140°F (-10° to 60°C)
storage relative humidity	20% to 95%

Weight and Dimensions

dimensions	12.9” x 18.7” x 8.8” (329 x 474 x 224 mm)
dimensions with input tray	329 x 474 x 544 mm
dimensions with input and output tray	586 x 474 x 934 mm
weight	44.5 lbs. (20.2 kg)
