160 Chapter 17: Control Groups
PRO1 Live Audio System
Operator Manual
VCA groups
There are eight VCA groups, which are accessible via the mix fader LCD select buttons
when configured for VCA operation.
VCA groups on the control surface and GUI
Item Description
1 LCD select button, selects the VCA group and is also used for group
member assignment.
2 VCA group control, adds its level control on top of the local channel fader
controls of the group members.
3 SOLO button activates signal routing from all assigned channels to the
monitor A section of the control centre. It is used to monitor the VCA
master faders by creating a mix on the solo buses, which consists of all
input channels and audio mix groups that are assigned to control from
corresponding VCA masters.
5
4
3
2
7
8
1
3
2
4
6
9
