480 Appendix J: Parameters Affected By Stereo Linking
PRO1 Live Audio System
Operator Manual
Aux Returns
This section shows the linked parameters of the return channels.
Input controls
This section shows the input control parameters that are linked across a channel pair.
Direct output
Not applicable.
Direct input
Not applicable.
Item Control Parameter
1 gain/[gain trim]
control knob
Digital trim level
2 input mode button For time aligning the return channel with the input
channels
3 EQ pushbutton EQ safe on/off
4 MIC pushbutton Mic safe on/off
5 FADER/[FDR] switch Fader safe on/off
6 MUTE/[MTE] switch Mute safe on/off
7 AUTO/[AUT] switch Auto safe on/off
1
1
2
1
5
4
6
7
3
5
4
6
7
3
