Midas PRO1 User Manual

Aux Returns (return channels) 527
PRO1 Live Audio System
Operator Manual
Aux Returns (return channels)
This section shows you which return channel parameters are affected by copy through
scenes.
Config sections
This section shows the configuration processing area parameters copied through
scenes.
* Depends on swap status.
** Only when sourced from a DL431 Mic Splitter.
Comp./Output Dyn
Not applicable.
Item Control Parameter
1 stage box control knob* Remote amplifier level
2 48V switch** 48V phantom voltage on/off
3 Filter switch (not shown in
GUI diagram above)**
30Hz filter in/out
4 input zone switch Input zone in/out
5 gain trim control knob* Digital input trim
6 delay control knob Delay time
4
DL431 Mic Splitter
input card
1
2
3
5
6
5
1
3
