390 Appendix F: Parameters Affected By Scope
PRO1 Live Audio System
Operator Manual
Effects rack
Each scope screen has a user-configurable rack of up to six effects in the Assignable
Effects section.
Note: A rack slot in the Assignable Effects section is equivalent to the All scope
area.
Patching
The diagram right shows the scoped
patching parameters of the effects, which
are on the Effects tab of the To section of
the Patching screen.
ABC D E F G H
Item Parameter
1 Input patching N/A No N/A N/A N/A N/A N/A N/A
