Midas PRO1 User Manual

324 Appendix C: Technical Specification
PRO1 Live Audio System
Operator Manual
Miscellaneous digital characteristics
Main processing functions
Main input channel functions
Type I/O Description Notes Connector
Word clock IN Accepts TTL level, 96kHz square wave;
impedance 75 ohms
BNC
Word clock OUT Provides TTL level, 96kHz square wave BNC
AES sync IN Accepts a 96kHz digital audio signal
conforming to AES3-2003
XLR
AES sync OUT Provides a 96kHz grade II reference
signal conforming to AES3-2003
XLR
Input channel hi pass 10Hz to 400Hz swept in digital domain
Slope selectable 12dB/Oct or 24dB/Oct
Input channel lo pass 2kHz to 20kHz swept in digital domain
Slope selectable 6dB/Oct or 12dB/Oct
Input channel treble Parametric Operation
Frequency 1kHz to 25kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Shelf Operation
Frequency 1kHz to 25kHz swept
Gain +16dB to –16dB
Soft, Classic or Bright (minimum harmonic disruption) curves
Input channel hi mid Parametric Operation
Frequency 320Hz to 8kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Input channel lo mid Parametric Operation
Frequency 80Hz to 2kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Input channel bass Parametric Operation
Frequency 16Hz to 400Hz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Shelf Operation
Frequency 16Hz to 400Hz swept
Gain +16dB to –16dB
Warm, Classic or Deep (minimum harmonic disruption) curves

Midas PRO1 Specifications

General

Type	Digital Mixing Console
Talkback	Yes
Channels	48 input channels
EQ Bands	4-band parametric EQ per channel
Outputs - Main	8 x XLR (on rear)
Display	15" TFT
Connectivity	Ethernet, USB, AES/EBU
