Midas PRO1 User Manual

Main processing functions 325
PRO1 Live Audio System
Operator Manual
Auxiliary input channel functions
Input channel
compressor
Peak, Linear, RMS, Vintage modes
Threshold -50dBu to +25dBu
Attack 200µs to 20ms
Release 50ms to 3 sec
Ratio 25:1 to 1:1
Knee 4dB, 12dB or 40dB
Gain 0dB to +24dB
Side chain source selectable + filter
Frequency 50Hz to 15kHz swept
Bandwidth 1/3, 1 or 2 Oct
Input channel gate Peak mode
Threshold -50dBu to +25dBu
Attack 20µs to 20ms
Hold 5ms to 2 sec
Release 2ms to 2 sec
Range 100dB to 0dB
Side chain source selectable + filter
Frequency 50Hz to 15kHz swept
Bandwidth 1/3, 1 or 2 Oct
Aux channel treble Treble Parametric Operation
Frequency 1kHz to 25kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Shelf Operation
Frequency 1kHz to 25kHz swept
Gain +16dB to –16dB
Soft, Classic or Bright (minimum harmonic disruption) curves
Aux channel hi mid Parametric Operation
Frequency 320Hz to 8kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Aux channel lo mid Parametric Operation
Frequency 80Hz to 2kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Aux channel bass Parametric Operation
Frequency 16Hz to 400Hz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Shelf Operation
Frequency 16Hz to 400Hz swept
Gain +16dB to –16dB
Warm, Classic or Deep (minimum harmonic disruption) curves

Midas PRO1 Specifications

General

Type	Digital Mixing Console
Talkback	Yes
Channels	48 input channels
EQ Bands	4-band parametric EQ per channel
Outputs - Main	8 x XLR (on rear)
Display	15" TFT
Connectivity	Ethernet, USB, AES/EBU
