Midas PRO1 User Manual

288 Chapter 31: Output Channels
PRO1 Live Audio System
Operator Manual
Mute, safes, level and solo
Each output fast strip (control surface and GUI) has controls for muting, soloing, safes
and output signal level control. This is supported on the GUI in the appropriate
processing area. They also each have a SELECT button for navigation. In addition, the
channel strips (control surface and GUI) have the full complement of safes.
Item Description
1 MUTE switch, mutes all post-processing signals leaving the channel. (In
addition to scene recall, muting can be remote from the auto-mute
masters.)
2 Safe LEDs, illuminate when their associated safe is on.
3 SOLO switch, activates signal routing to the monitor A section of the
control centre.
GUI fast strip
Masters processing
area in the GUI
channel strip
Channel processing area
GUI output fast strip
Mix channel strip
1
3
7
1
8
3
7
1
8
3
7
6 5 4
6
2
5 2 4 2
