326 Appendix C: Technical Specification
PRO1 Live Audio System
Operator Manual
Output channel functions
Output channel band 6 Parametric Operation
Frequency 16Hz to 25kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Lo Pass Operation
Frequency 16Hz to 25kHz swept
Slope 6dB/Oct or 12dB/Oct
Shelf Operation
Frequency 16Hz to 25kHz swept
Gain +16dB to –16dB
Mode soft curve
Output channel bands 3,
4 and 5
Parametric Operation
Frequency 16Hz to 25kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Output channel band 2 Parametric Operation
Frequency 16Hz to 25kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Hi Pass Operation
Frequency 16Hz to 25kHz swept
Slope 24dB/Oct
Output channel band 1 Parametric Operation
Frequency 16Hz to 25kHz swept
Gain +16dB to –16dB
BW 0.1 Oct to 3 Oct
Hi Pass Operation
Frequency 16Hz to 25kHz swept
Slope 6dB/Oct or 12dB/Oct
Shelf Operation
Frequency 16Hz to 25kHz swept
Gain +16dB to –16dB
Mode soft curve
Output channel GEQ 8 available in place of PEQ (above)
31 Bands, 1/3 Oct, Proportional Q
Lo Pass Frequency 2kHz to 20kHz swept
Slope 6dB/Oct or 12dB/Oct
Hi Pass Frequency 20Hz to 500Hz swept
Slope 6dB/Oct or 12dB/Oct
Output channel dynamic Pk, Linear, RMS, Vintage, Shimmer modes
Threshold -50dBu to +25dBu
Attack 200µs to 20ms
Release 50ms to 3 sec
Ratio 25:1 to 1:1
Knee 4dB, 12dB or 40dB
Gain 0dB to +24dB
Side chain source selectable + filter
Frequency 50Hz to 15kHz swept
Bandwidth 1/3, 1 or 2 Oct
