Midas PRO1 User Manual

162 Chapter 17: Control Groups
PRO1 Live Audio System
Operator Manual
POPulation groups
There are six POPulation groups. Although similar to VGA groups in their methods of
group management and selection, they have limited functionality.
POPulation groups on the control surface and GUI
Item Description
1 LCD select button, selects the VCA group and is also used for group
member assignment.
2 unfold button, assigns the POPulation group to the control surface,
unfolding the group members to the channel faders.
3 POPulation group ID — fixed and user-configured name of group.
1
3
2

Midas PRO1 Specifications

General

Type	Digital Mixing Console
Talkback	Yes
Channels	48 input channels
EQ Bands	4-band parametric EQ per channel
Outputs - Main	8 x XLR (on rear)
Display	15" TFT
Connectivity	Ethernet, USB, AES/EBU
