Midas PRO1 User Manual

Inputs 405
PRO1 Live Audio System
Operator Manual
* Depends on swap status.
** Only when sourced from a DL431 Mic Splitter.
AUTO (automation) safe
All of the input channel parameters are protected by the AUTO safe — except, of
course, for the ones unaffected by the safes (see “Input parameters not affected by the
safes” on page 399).
6
Ø switch
Input phase invert on/off
7 Level control knob Direct output level
8 MODE switch Direct output tap-off point: “Post-fade and mute”,
“Pre-mute, pre-processing” or “Pre-mute, post-
processing”
9 dest button, text field Direct output tap-off point
10 INS switch Insert in/out
Item Control Parameter

Midas PRO1 Specifications

General

Type	Digital Mixing Console
Talkback	Yes
Channels	48 input channels
EQ Bands	4-band parametric EQ per channel
Outputs - Main	8 x XLR (on rear)
Display	15" TFT
Connectivity	Ethernet, USB, AES/EBU
