490 Appendix J: Parameters Affected By Stereo Linking
PRO1 Live Audio System
Operator Manual
Dynamics
This section shows the compressor control parameters that are linked across a channel
pair. Only corrective compressor shown below, but this is typically the same for the
other compressor modes.
Item Control Parameter
1 ON switch Compressor on/off
2 release control knob Compressor release
3 threshold control
knob
Compressor threshold
4 KNEE pushbutton Compressor knee: hard, medium or soft
5 IN switch Compressor sidechain in/out
6 freq control knob Compressor sidechain frequency
7 WIDTH pushbutton Compressor sidechain width: 2 Oct, 1 Oct or
0.3 Oct
8 ratio control knob Compressor ratio
9 attack control knob Compressor attack
2
3
11
4
5
10
6
7
8
9
10
2
3
11
7
5
6
4
8
9
1
1
3
