How to patch 63
PRO1 Live Audio System
Operator Manual
To quickly check the destinations of a source patch connector, click it. This will
select it and all of its destinations. A green triangle will appear under the name
of any tab in the To section that contains a destination(s).
>> To select a block of patch connectors in the From section
Use a drag operation to create a bounding box
around the desired connections (typically shown
right).
This procedure can only be done during sequence and
multi-patching operations (initiated by the SEQ. and
AUTO buttons, respectively).
>> To deselect all selected patch connectors
Click NONE.
>> To remove a single patch
In the To section, click the patch connector from which you want to remove the patch.
>> To remove all the patches of a single source
1 Make sure that no patch connectors are selected. If necessary, click NONE.
2 In the From section, click the source patch connector from which you want to
remove all of the patches. (This will select the source patch connector and also
all of its destinations.)
3 Click CLEAR SEL.
>> To remove the patches from all selected patch connectors
Click CLEAR SEL.
>> To clear a block of patch connectors
1 Click NONE.
2 In the From section, select the patch connectors you want to unpatch.
3 Click CLEAR SEL.
4 Click NONE.
Deselect the patch connector, which then
reverts to its previous state (patched
or unpatched ).
Remove the patch ( ).
Select the patch connector ( ) and all
the ones it is patched to in the To
section. (A green triangle under a tab
title shows that its tab contains one or
more selected patch connectors.)
Remove the patch ( ).
Click To do this in the From section To do this in the To section
