Technical Information
153
G 5xxx
Figure 100-1: Screws Securing the Fascia Panel (Touchtronic/Navitronic)
To re-install, first install the fascia panel and screw it into position, then
restore the switch buttons.
4.2 Fascia Panel Removal (Incognito)
1. Uninstall the appliance.
2. Disconnect the appliance from the power supply.
3. Remove the retaining screws (Figure 100-2, Item 1).
4. Take off the pushbuttons.
5. Slide the fascia panel upwards.
