Technical Information
35
G 5xxx
Figure 010-2: Drip Pan Removal
Warning!
When re-installing, it is vital to ensure that screws with a serrated surface
under their heads are used to secure the drip pan to the connection strip.
This is absolutely essential to ensure a good ground connection.
4.3 Hinge Removal
Note: Hinges must be replaced in pairs.
1. Uninstall the appliance.
2. Disconnect the appliance from the power supply.
3. Remove the outer door panel. See Section 030-4.1.
4. Remove the left and right side panels; see Section 010-4.1.
5. Close the door.
6. Release the spring tension.
7. Unhook the door spring cords (see Figure 010-3, Item 1).
8. Bend the hinge upwards using pliers (see Figure 010-3, Item 2).
Figure 010-3: Opening the Hinge Bracket
