Technical Information
52
G 5xxx
Note:
Adjust the locking plate so that the door seal is not excessively crushed and
not under excess pressure when the door is closed (see Figure 020-14, Item
A). The locking plate can be adjusted by 1 millimeter in either direction.
Figure 020-14: Door Seal with Door
4.4 Bottom Door Seal Removal
1. Uninstall the appliance.
2. Disconnect the appliance from the power supply.
3. Remove the door outer panel. See Section 030-4.3.
4. Remove the cable holder. See Section 020-4.2.
5. Using needlenose pliers, squeeze together each of the retainers at the
top of the bottom door seal’s plastic holder (Figure 020-15, Item 1; one
per side). Pull the top of the plastic holder away from the door inner
panel.
6. Remove the bottom of the plastic holder from the U-shaped slot in the
door inner panel (Figure 020-15, Item 2).
Note:
When re-installing the door seal, ensure that the seal holder is reseated in
the U-shaped slot in the door inner panel. See Figure 020-15, Item 2.
