Miele PG 8591 - Built-Under Installation; Building Under a Continuous Worktop

Installation
*INSTALLATION*
138
Building under a continuous worktop
Removing the
lid
To build the machine under a continuous worktop the lid must be
removed as follows:
 Unscrew both securing screws from the lid at the back of the
machine.
 Open the door.
 Unscrew the left and right fixing screws.
 Lift the lid off.
Steam condenser
To avoid steam damage to the worktop, the protective foil supplied
(25x58cm, self-adhesive) must be applied underneath the
worktop in the area of the steam condenser.
Prevent heat
build-up
During the drying phase hot exhaust air is discharged from the wash
cabinet through the steam condenser on the back of the machine. To
avoid heat build-up and excessive condensation, sufficient air
circulation must be ensured.
 Leave at least 10 mm (0.39 in) space between machine and
worktop for air circulation.
 Install ventilation grills in the side cabinets if necessary.
