Miele PG 8591 - Technical Data

Technical data
145
Imperial Metric
Height with machine lid
Height without machine lid
32 7/8"
32 5/16"
835mm
820mm
Width
23 9/16" 598mm
Depth
Depth with door open
23 9/16"
47 1/4"
598mm
1,200mm
Wash cabinet dimensions:
Height
Width
Depth of upper basket/lower basket
20 9/16"
21 1/8"
20 9/16"
520mm
530mm
474mm/520mm
Weight (net)
172 lbs 78kg
Max. load capacity of open door
81.6 lbs 37kg
Voltage, rated load, fuse rating See data plate See data plate
Power cable
Approx. 5' 9" ft. Approx. 1.8m
Water intake temperature:
Cold water/steam condenser
Hot water/DI water
max. 68 °F
max. 149 °F
Max. 20°C
Max. 65°C
Static water pressure
max. 145 psi Max. 1,000kPa pressure
Minimum water intake flow pressure:
Cold water/steam condenser
Hot water
DI water
14.5 psi
5.8 psi
4.4 psi
100kPa pressure
40kPa pressure
30kPa pressure
Recommended water intake flow pressure:
Cold water/hot water
DI water
Steam condenser
29 psi
29 psi
14.5 psi
≥200kPa pressure
≥200kPa pressure
≥100kPa pressure
Drain height
min. 11 3/4" ft, max. 3' 3" ft Min. 0.3m, max. 1.0m
Drain hose length
max. 13' 1" ft Max. 4.0m
Operation (according to IEC/EN61010-1):
Ambient temperature
Relative humidity maximum
linear decrease to
Relative humidity minimum
40 °F to 104 °F
80% for temperatures up to 88 °F
50% for temperatures up to 104 °F
10%
5°C to 40°C
80% for temperatures up to 31°C
50% for temperatures up to 40°C
10%
Storage and transportation conditions:
Ambient temperature
Relative humidity
Air pressure
- 4°F to 140°F
10% to 85%
7.25psi to 15.37psi
- 20°C to 60°C
10% to 85%
500hPa to 1060hPa
Altitude above sea level (according to IEC/
EN61010-1)
up to 4,921 ft* Up to 2,000m*
Ingress protection (according to IEC 60529)
IP21
Soiling level (according to IEC/EN61010-1)
2
Overvoltage category (according to IEC60664)
II
Sound emission values in dB (A),
sound pressure level LpA during cleaning and
drying phases
<59
Certifications CAN/CSA-C22.2 No. 61010-1-04, CAN/CSA-C22.2 No. 61010-2-040,
UL Std. No. 61010-1 (2nd Edition), IEC 61010-2-040:2006
Manufacturer’s address Miele & Cie. KG, Carl-Miele-Straße 29,
33332 Gütersloh, Germany
* If installed above 4,921ft (2,000m), the boiling point of the wash water will be lower. In this case, the disinfecting
temperature and the holding time will need to be reset by Miele Service.
