Application technology
36
Wash pressure measurement
The wash pressure can be measured on all wash carts and baskets
with spray arms, injector bars, or other wash connections, e.g. during
performance tests and validations in accordance with EN ISO 15883.
Test point for
measuring wash
pressure
On wash carts and baskets with spray arms and additional injector
bars or other wash connections, there is a connection on the injector
bar or a wash connection for wash pressure measurement. The exact
location is described in the respective operating instructions for the
wash carts and baskets.
On wash carts and baskets with spray arms and no additional wash
connections, access for the wash pressure measurement is provided
on the side of the water supply pipe.
Under no circumstances may items to be washed, washing
attachments etc., be connected to the test point. After the
measurement, the test point must be closed again with the blind
stopper.
