P663 TEMPERATURE TRANSDUCER ALLOCATION
This feature may only be used for "differential" or "average"
Operation (P001 = 4 or 5).
As preset, the temperature measurements of Ultrasonic / Temperature
Transducer # 1 and 2 are allocated to Point Number 1 and 2 respectively.
Use this feature (if desired) if the temperature measurement from both
transducers should be identical, however one transducer is mounted in direct
sunlight (or near some other radiant heat source). Allocate the temperature
measurement of the other transducer to both transducer Point Numbers.
Enter the Transducer Number whose temperature measurement will be
used for the distance calculation of the Point Number displayed.
When both transducers are allocated to a Point Number, the temperature
measurements from each transducer are averaged.
values: 1 = Transducer # 1
2 = Transducer # 2
1.2 = Transducer # 1 and 2 average
P664 (V) TEMPERATURE
View the transducer acoustic beam atmosphere temperature in °C.
This is the value displayed when is pressed in the RUN mode.
If Temp Source (P660) is set to any value other than Fixed Temp, the value
displayed is the temperature measured. If Temp Source is set to Fixed
Temp, the P661 value is displayed.
values: -50 to 150
PARAMETERS
PL-507 125
