INTRODUCTION
ABOUT THIS MANUAL
This instruction manual provides information specific to the Milltronics
HydroRanger
Plus
(HYDRO+) level monitor
*
. Other products (including transducers) associated with
a HYDRO+ based level monitoring system, are supplied with individual instructions.
All general start up information is included in the white pages. Refer to the grey pages
for additional information or technical assistance, if required.
After reading this INTRODUCTION and completing the physical INSTALLATION, first
time system installers may wish to use the
HYDRORANGER PLUS Quick Start
Guide, PL-439
for step by step start up instructions.
INTRODUCTION
briefly describes key features.
INSTALLATION
step by step mounting and wiring procedure.
PROGRAMMING
program mode LCD and keypad functions.
OPERATION
run mode LCD and keypad functions.
APPLICATIONS
10 brief examples of common HYDRO+ uses.
PARAMETERS
specific programmable feature definitions.
TECHNICAL REFERENCE
detailed information for complex features.
TROUBLESHOOTING GUIDE
quick problem solving techniques.
SPECIFICATIONS
lists physical and operational characteristics.
PROGRAMMING CHART
space to record all programming for future
reference. (Also used as a Parameter index).
REMEMBER!
"Programming is not complete until the Programming Charts are completed".
*
This manual applies to the wall, rack, and panel mount HYDRO+ versions.
For simplicity, the rack mount version is illustrated only
where necessary to identify version differences.
Throughout this manual (unless stated otherwise) "level" refers to the
relative position of a monitored liquid surface.
INSTALLATION
INTRODUCTION
INTRODUCTION
PL-507 5
