APPLICATIONS
The following examples illustrate how easily the HYDRO+ may be programmed to
meet specific application requirements.
While your installation may not match these examples exactly, by reviewing the
closest example (or combination of examples), the relationship between HYDRO+
features and your process measurement requirements may be more easily identified.
In every case, refer to General Application. This example defines the minimum
programming required for any application. Then refer to the applicable "add on"
examples for programming information specific to your application.
If additional parameter detail is required, (than provided in these examples), see
PARAMETERS for complete parameter definitions.
Ensure all alarms and controls are disabled until all application programming is
complete and satisfactory RUN mode performance is verified.
1. General Application (common programming to all applications).
2. Wet Well Control add on (combine with example 1).
3. Reservoir Control add on (combine with example 1).
4. Screen Rake Control add on (combine with example 1).
5. Penstock Control add on (combine with example 1).
6. General Alarm add on (combine with example 1).
7. Volume Calculation add on (combine with example 2 or 3).
8. Pumped Volume Calculation add on (combine with example 2 or 3 and 7).
9. OCM Flow Calculation add on (combine with example 1).
10. Failsafe Operation add on (combine with example 1 to 5).
