RELAY PARAMETERS
Alter the following parameters as required.
STANDARD RELAY CONFIGURATIONS (P100)
These parameters set up Independent Relay Parameters to satisfy the most common
relay operation requirements, requiring only one programming entry.
P100 (G) RELAY SET UP
Enter the Relay Set Up (if desired) to preset numerous relay parameters
as required for common HYDRO+ applications.
If the Relay Set Up selected, exactly matches HYDRO+ relay operation
requirements, no further relay programming is necessary.
If the Relay Set Up selected does not exactly match relay operation
requirements, modify the Relay Set Up by independently programming
the remaining relay parameters as required.
If completely independent relay programming is desired, enter "0" and
proceed to Independent Relay Programming.
The "screen control" Relay Set Up may only be selected after "differential"
Operation (P001 = 4) is selected.
Entering any Relay Set Up value automatically resets all relay
programming to the Relay Set Up specified.
values: 0 = all relays off
1 =
Wet Well 1
(see APPLICATIONS Wet Well Control)
2 =
Wet Well 2
(similar to above except pump by rate)*
3 =
Reservoir 1
(see APPLICATIONS Reservoir Control)
4 =
Reservoir 2
(similar to above except pump by rate)*
5 =
Screen Control
(see APPLICATIONS Rake Control)
6 = General Alarms (see APPLICATIONS General Alarms)
* Pumps are activated by rate of rise / fall rather than by specific
level setpoints. See Rate Pump (P121).
