INTERCONNECTION
Verify all HYDRO+ system components have been installed in accordance with the
associated product instruction manuals.
Connect all cable shields to the HYDRO+ shield connections. To avoid differential
ground potentials, do not connect cable shields to ground (earth) elsewhere. Insulate
(tape) cable shields at all shield junctions to prevent ground loops
SYSTEM DIAGRAM
HydroRanger
Plus
Milltronics transducer,
see Specifications
Milltronics TS-3
temperature sensor
(optional)
customer
device
customer alarm, pump
or control device
mA output
relay output
mA input
customer
device
PL-507 18
