QUICK START PARAMETERS (P001 TO P009)
P001 (G) OPERATION
Enter the type of RUN mode operation desired.
If "out-of-service" is entered, the transducer is not fired, alarm relay(s)
energize, pump relay(s) de-energize, and mA output(s) assume the surface
is at the Empty (P-006) value.
*
If "DPD" or "DPA" is entered, 2 transducers are required, see
INSTALLATION Transducer.
DPD = Point 3 = Point 1 - Point 2.
DPA = Point 3 = (Point 1 + Point 2) 2.
values: 0 = out-of-service
1 = level (display how full a vessel is)
2 = space (display how empty a vessel is)
3 = distance (preset, surface to transducer face distance)
4 = DPD (display the absolute difference between 2 levels)
5 = DPA (display the average of 2 levels)
6 = OCM (display flow in an open channel)
7 = PT (display total pumped volume)
P002 (G) MATERIAL
Enter the type of material monitored.
values: 1 = liquid or flat solid surface (preset)
2 = solid (heaping or angled away from transducer)
P003 MEASUREMENT RESPONSE
Enter the typical monitored surface rate of change in position.
This feature presets a variety of independently programmable parameters,
substantially simplifying start up requirements.
If Failsafe, Rate, Measurement Verification, or Scanning parameters have
been previously independently programmed, refer to
TECHNICAL REFERENCE Measurement Response before altering.
values: 1 = slow (0.1 m/min)
2 = medium (1 m/min) (preset)
3 = fast (10 m/min)
