MIMAKI CG-60SL User Manual

3-12
Expand the cutting (plotting) area
You can reduce the dead space to expand cut (picture drawing) area (EXPANDS function).
Each of the right and left non-plotting areas is reduced by 10 mm.
Set the EXPANDS function to ON.
1
Press the key in the local
mode.
2
Press the jog key or key to
select [SET UP] .
3
Press the key.
4
Press the jog key or key to
select [EXPANDS] .
Pinch roller (left) Pinch roller (right)
EXPANDS: OFF
EXPANDS: ON
When the sheet is set in the rear
DATA CLEAR <ENT>
FUNCTION
SET UP <ENT>
ENTER/HOLD
EXPANDS <en t >

MIMAKI CG-60SL Specifications

General

Type	Cutting Plotter
Cutting Method	Drag Knife
Maximum Media Thickness	0.25 mm
Blade Type	Standard Blade
Interface	USB 2.0
Power Requirements	50/60 Hz
Weight	25 kg
Maximum Cutting Speed	500 mm/s
Cutting Force	20 – 250 g
Power Supply	AC 100-240 V
Operating Temperature	5 – 35 °C
Operating Humidity	35-80% RH (non-condensing)
Dimensions (W x D x H)	950 mm x 430 mm x 330 mm (37.4 in x 16.9 in x 13.0 in)
