2-39
2
Basic Operations
Head Cleaning
About head cleaning
There are two types of head cleaning.
Depending on the test printing result, perform to solve nozzle clogging.
Check the printed test pattern result and perform cleaning depending on the status.
Select one from the three types below:
NORMAL : When any line is missing
SOFT : When only head wiping is needed (when lines are bent)
HARD : When poor image quality cannot be improved even by NORMAL or SOFT cleaning
Perform when using silver ink or white ink of ES3 ink.
(available for the firmware Ver.2.40 and later)
Pigments of silver ink and white ink of ES3 ink have nature of settling down when they are left for a long time
without being used, and it may cause color heterogeneity.
By performing “spot” of head cleaning to discharge ink settling down, you can improve color heterogeneity (spot
color maintenance function).
spot : By discharging special ink whose pigment remains settling down in the head, the damper or the tube
of this machine, improve color heterogeneity.
Perform head cleaning depending on the test printing result
There are three types of head cleaning. Use one by checking the test pattern.
1
Press the key in LOCAL to select the
printing mode.
2
Press the key.
3
Press to select a type of cleaning.
NORMAL : When any line is missing
SOFT : When only head wiping is needed (when lines are bent)
HARD : When poor image quality cannot be improved even by NORMAL or SOFT cleaning
4
Press the key.
• The remaining cleaning time is indicated in the lower part of the
display.
• When cleaning has ended, the screen returns to LOCAL.
5
Perform test printing again to check the result.
• Repeat the cleaning and test printing until the result becomes normal.
• Spot color maintenance is selectable only when silver ink or white ink of ES3 ink has been filled for the
firmware Ver.2.40 and later.
When image quality is not improved even though head cleaning is repeated:
• Clean the wiper and ink cap. ( P.6-6)
• Wash the nozzle head. ( P.6-11)
• See "When Nozzle Clogging Cannot Be Solved" to improve poor image quality. ( P.6-18)
To Next Page
