Chapter 4 Maintenance
Replacing Consumables
To order replacement consumable items, contact your
local dealer or our service office. For more information on
consumable items, refer to our website.
https://mimaki.com/supply/inkjet.html
Replacing wipers
When a [Replace Wiper] warning message is displayed,
the wiper must be replaced with a new one. Also at this
time, wipe away ink adhering to the bottom of the slider.
1
With the screen in local mode, select
[MENU] > [MAINTENANCE], and then press
the [ENTER] key.
• The Maintenance menu is displayed.
2
Select [STATION MAINT.] > [REPLACE
WIPER], and then press the [ENTER] key.
• The carriage moves over the platen.
3
Remove the wiper.
• Pull out the wiper by holding the lugs at both
ends.
4
Clean the wiper slider.
• Use a cleaning stick moistened with maintenance
liquid to wipe off any adhering ink or dust. Wipe
off the maintenance liquid. Make sure none
remains.
5
Insert a new wiper.
• Holding the wiper by the lugs at both ends, push it
in.
6
Press the [ENTER] key.
• After initialization, the machine returns to local
mode.
Replacing exhaust box filters
Check the exhaust fan filter condition. Replace if very
dirty.
1
Remove the exhaust fan box.
• Push the tabs at the front to remove the exhaust
fan box.
2
Attach a new exhaust fan filter to the
exhaust fan box.
• Insert the exhaust fan filter into the space under
the tabs of the exhaust fan box.
• After a wiper replacement warning appears,
confirm that the top edge of the wiper film is free
of damage or fluff, etc. If there is no damage or
fluff at the top edge of the wiper film, it can still
be used.
• Replace the very dirty exhaust fan box with new
one.
