Chapter 6 Appendix
6-2
Specifications
Main unit specifications
Item TxF150-75 Remarks
Head
On-demand piezo head
(1 head, 8 nozzles; 180 nozzles per line; pitch between nozzles:
180 dpi)
Print resolution
x-dpi: 720/1440
y-dpi: 720
Variable dot is sup-
ported
Ink CMYK + W
6 IC chip-equipped
cartridges in total
Ink supply Ink end: weight entry + internal count
Ink capacity 1 each of 600ml cartridge CMYK, 2 each of 500ml cartridge W
Compatible media Film
Maximum printing width 800mm
At minimum hori-
zontal dead space
Media specifi-
cations
Maximum width 810mm
Minimum width 210mm
Thickness Max. 1.0 mm
Roll outside
diameter
Max. 250 mm
Roll weight
Max. 45 kg
No feed failures due to sagging caused by weight when the roll is
retained at both ends
Roll inside
diameter
2 inches or 3 inches
Print side Inside/outside (not required)
Take-up treat-
ment
Taped or loosely affixed to paper core
Margin
Roll Left and right: 15 mm (default)Front: 120 mmRear: 150 mm
Tolerance excluding
media skewing: 2 mm
Left/right margins:
changeable Min. 5
mm
Leaf Left and right: 15 mm (default)Front: 120 mmRear: 150 mm
Origin alignment (LED pointer)
Alignment with the LED pointer mounted on the head actuator
Use pointer to change the plotting origin to a value that exceeds
the initial value.
Excluding media size
variation
Excluding initial load-
ing fluctuations
Distance accu-
racy
Absolute accu-
racy
± 0.3 or ±0.3% of specified distance, whichever is larger
Reproducibility ± 0.2 or ±0.1 % of specified distance, whichever is larger
Perpendicularity ± 0.5/ 1,000
Media skew 5 or less / 10 m
Printing gap Manual, three settings (2.0, 2.5, 3.0)
Media heater
PRE/PRINT/AFTER: 50/50/50
Independent control of the three systems
Ink sediment cycle Provided for W
UISS Provided
Cleaning cartridge Provided
Nozzle Missing Detector (NCU) Provided
Media cutting
Standard
Cutting precision (steps): 0.5 mm or lower
Waste Ink Tank Bottle type (2000 ml)
Image memory 256MB SD-RAM
Interface Standard
1) USB 2.0
2)Ethernet；1000BASE-T
Command MRL- IV
MAPS MAPS4
Noise levels
During standby
45 dB or lower （ FAST-A, 1 m on all sides）
During continu-
ous printing
60 dB or lower
During discon-
tinuous printing
70 dB or lower
