A5/A3™ Service Manual 046-001141-00 2 - 29
Installation Guide Functional Tests
FIGURE 2-40 O2 Sensor Calibration
2. The calibration screen as shown below is displayed when Begin is selected. During the
calibration, you can select Cancel to cancel the calibration.
FIGURE 2-41 O2 Sensor Calibration in Progress
3. The screen shown below is displayed if the ongoing calibration is canceled. Select Try Again to
repeat the calibration. Select Done to exit the calibration screen.
To Next Page
