A5/A3™ Service Manual 046-001141-00 1 - 5
Theory of Operation Electrical and Pneumatic Connections
No. Description P/N
B1 Power Board 801-0631-00025-00
B2 Battery Interface Board 801-0631-00109-00
B3 Mother Board 801-0631-00108-00
B4 Warning Light Board 801-0631-00019-00
B5 Indicator Light Board 801-0631-00004-00
B6 Touch Screen Control Board 801-0631-00018-00
B7 Display Interface Board 801-0631-00017-00
B8 A3 CPU Board 801-0633-00004-00
B9-11 Ventilator Control Board 801-0631-00027-00
B12 Sensor Interface board 801-0631-00089-00
B13 Top Lighting Board 801-0631-00039-00
B14 Fresh Flow Sensor Board 801-0631-00040-00
B15 Aux FlowMeter Lighting Board /
P1 Filter Power 250VAC 15A Panel Mount (0633) 801-0633-00003-00
P2-4 Auxiliary Output Socket 801-0631-00032-00
P5-7 Breaker (3.0A) 801-0631-00031-00
P8 Lithium-ion Battery 115-018012-00
P9 Speaker and Connecting Cable 801-0631-00038-00
P10 Fan 801-0631-00028-00
P11 Drive Gas Assembly
801-0631-00047-00
115-020937-00(For
software version 03.04.00
and later,)
P12 Display Exchange Package 801-0631-00075-00
P13 Circuit Heater 115-034450-00
P14 Solenoid valve assembly 801-0631-00046-00
P15 A5 Calibration set FRU 801-0631-00121-00
P16 Touch Screen 801-0631-00014-00
#1 Cable, battery 009-000969-00
#2 Cable, Patient Monitor 009-000971-01
#3 Cable, System Switch 009-001776-00
#4 Cable, Indicator 009-000977-00
#5 Cable, Ventilator 009-000979-00
#6 Cable, Breathng System 009-000980-00
#7 Cable, Sodalime Canister Switch Cable 009-000987-00
#8 Cable, Circuit Switch 0621-20-78593
#9 Cable, O2 Pressure Switch 0621-20-69588
#10 Cable, Top Lighting A 009-000982-00
#11 Cable, Lighting Switch 009-000981-00
#12 Cable, AC Power Cable 009-002224-00
#13 Cable, Power, AC Internal 009-000985-01
#14
Cable, Inverter Cable(old)
Cable,LED Backlight Input(new)
009-000988-00 (old)
009-006382-00 (new)
