Electrical and Pneumatic Connections Theory of Operation
1 - 6 046-001141-00 A5/A3™ Service Manual
#15 Cable, Display 009-000973-00
#16 Cable, Touch Screen 009-000978-00
#17 Cable, Alarm 009-000976-00
#18
Cable, Inverter LED (old)
Cable,Screen Backlight (new)
NOTE: When there is a Screen Backlight Board (See
section 1.6.1.3 (pg. 1-43) "Screen Backlight
Board"), please use the new cable.
009-000974-00 (old)
009-006731-00 (new)
#19 Cable, Display Lighting 009-000986-00
No. Description P/N
