Mindray A3 Service Manual

Electrical and Pneumatic Connections Theory of Operation
1 - 8 046-001141-00 A5/A3™ Service Manual
No. Description P/N
B1 Power Board 801-0631-00025-00
B2 Battery Interface Board 801-0631-00109-00
B3 Mother Board 801-0631-00108-00
B4 Warning Light Board 801-0631-00019-00
B5 Indicator Light Board 801-0631-00004-00
B6 Touch Screen Control Board 801-0631-00018-00
B7 Display Interface Board 801-0631-00017-00
B8 A5 CPU Board PCBA 801-0631-00026-00
B9-11 Ventilator Control Board 801-0631-00027-00
B12 Sensor Interface board 801-0631-00089-00
B13 Top Lighting Board 801-0631-00039-00
B14 Fresh Flow Sensor Board 801-0631-00040-00
B15 Aux FlowMeter Lighting Board /
B16 Infrared Communication Board 801-0621-00165-00
B17 AG Module 6800-30-50502
P1 Filter Power 250VAC 10A Panel Mount (0631) 801-0631-00029-00
P2 Breaker (10.0A) 801-0631-00030-00
P3-6 Auxiliary Output Socket 801-0631-00032-00
P7-10 Breaker (3.0A) 801-0631-00031-00
P11-12 Lithium-ion Battery 115-018012-00
P13 Speaker and Connecting Cable 801-0631-00038-00
P14 Fan 801-0631-00028-00
P15 Touchpad 801-0631-00052-00
P16 Drive Gas Assembly
801-0631-00047-00
115-020937-00(For
software version
03.04.00 and later,)
P17 Display Exchange Package 801-0631-00075-00
P18 Circuit Heater 801-0631-00069-00
P19 Solenoid valve assembly 801-0631-00046-00
P20 A5 calibration set FRU 801-0631-00121-00
P21 Touch Screen 801-0631-00014-00
P22 Fan 024-000407-00
#1 Cable, battery 009-000969-00
#2 Cable, Patient Monitor 009-000971-01
#3 Cable, Touchpad 009-000972-00
#4 Cable, System Switch 009-001776-00
#5 Cable, Ventilator 009-000979-00
#6 Cable, Breathng System 009-000980-00
#7 Cable, Sodalime Canister Switch Cable 009-000987-00
#8 Cable, Circuit Switch 0621-20-78593
#9 Cable, O2 Pressure Switch 0621-20-69588
#10 Cable, Top Lighting A 009-000982-00
