A5/A3™ Service Manual 046-001141-00 1 - 9
Theory of Operation Electrical and Pneumatic Connections
#11 Cable, Lighting Switch 009-000981-00
#12 Cable, Auxiliary Outlet 009-000984-00
#13 Cable, Power, AC Internal 009-000985-01
#14 Cable, Indicator 009-000977-00
#15 Cable, Display 009-000973-00
#16 Cable, Touch Screen 009-000978-00
#17 Cable, Alarm 009-000976-00
#18
Cable, Inverter LED (old)
Cable,Screen Backlight(new)
009-000974-00 (old)
009-006731-00 (new)
#19
Cable, Inverter Cable(old)
Cable,LED Backlight Input(new)
NOTE: When there is a Screen Backlight Board (See
section 1.6.1.3 (pg. 1-43) "Screen Backlight
Board"), please use the new cable.
009-000988-00 (old)
009-006382-00 (new)
#20 Cable, Display Lighting 009-000986-00
No. Description P/N
