A5/A3™ Service Manual
046-001141-00
6 - 33
Repair and Disassembly
Disassemble the Assemblies
4.
Remove the two scr
e
ws on the touch scr
een control boar
d to remo
ve the board.
FIGURE 6-59
6.2.4.4
Remo
ve the Back
light Inv
er
ter Board
1.
Remove displa
y assembly.
2.
Remove the f
our screws and the cover pl
ate of the back
light inverter board.
FIGURE 6-60
3.
Unplug the re
lated cables from
the backlight inverter board.
372
