BeneVision N Series Patient Monitor Operator’s Manual C - 17

FiO

Alarm switch On

High limit Adult and pediatric: 100%

Neonate: 90%

Low limit 18%

Priority Med

Alarm Outputs Off

EtN

O Alarm switch On

High limit 55%

Low limit 0%

Priority Med

Alarm Outputs Off

FiN

O Alarm switch On

High limit 53%

Low limit 0%

Priority Med

Alarm Outputs Off

EtAA/FiAA Alarm switch On

High limit 30%

Low limit 0.0%

Priority Med

Alarm Outputs Off

EtHal/EtEnf/EtIso Alarm switch On

High limit 3.0%

Low limit 0.0%

Priority Med

Alarm Outputs Off

FiHal/FiEnf/FiIso Alarm switch On

High limit 2.0%

Low limit 0.0%

Priority Med

Alarm Outputs Off

EtSev Alarm switch On

High limit 6.0%

Low limit 0.0%

Priority Med

Alarm Outputs Off
