D - 8 BeneVision N Series Patient Monitor Operator’s Manual
D.2.11 CCO
Technical Alarm Messages (From PiCCO Module)
D.2.12 CO
2
Technical Alarm Messages
ICG Low Signal Quality Low C Poor ICG sensor connection or high
electromagnetic interference.
1. Check the sensor connection, re-apply the
sensor if necessary.
2. Check if there is high electromagnetic
interference. If yes, remove it.
3. If the alarm persists, contact your service
personnel.
ICG No Cable Low A Check and reconnect the cable.
ICG Sensor Off Low A Check and reconnect the sensor.
Alarm message Default priority
Indication on
alarm reset
Cause and solution
Alarm message Default priority
Indication on
alarm reset
Cause and solution
Invalid PiCCO Catheter Low C Erroneous or invalid catheter is used. Replace the
catheter with the recommended catheter.
TI /TB Sensor Off Low A Check the sensor connections.
TI Sensor Error Low C Replace the sensor.
Invalid CCO calibration Low C The arterial pressure is invalid. Check the pArt
measurement.
Alarm message Default priority
Indication on
alarm reset
Cause and solution
CO2 Module High Temp Low C Ambient temperature is too high or there is a
module failure.
1. Lower the operating temperature.
2. Replug the module.
3. If the alarm persists, the CO
2
module may fail,
contact your service personnel.
CO2 Module Low Temp Low C Ambient temperature is too low or there is a
module failure.
1. Raise the operating temperature.
2. Replug the module.
3. If the alarm persists, the CO
2
module may fail,
contact your service personnel.
CO2 Zero Failed Low C For mainstream CO
2
module, check the
connections between the adapter and CO
2
transducer. Wait till the sensor’s temperature
becomes stabilized, and then perform a zero
calibration again.
For sidestream CO
2
module, replug the module. If
the alarm persists, contact your service
personnel.
CO2 No Watertrap Low B Check the watertrap connections.
