BeneVision N Series Patient Monitor Operator’s Manual 25 - 7
25.8.8 Setting Parameters for Display
Each numeric areas of Paw, Flow or Vol can display up to 6 parameters. To set the parameters for display, follow
this procedure:
1. Select the numeric area or waveform area of Paw, Flow or Vol to enter the RM menu.
2. Select the Select Parameter tab.
3. Select the parameters for display on pages of Paw, Flow and Vol.
25.8.9 Entering the Intubation Mode
When performing intubation during general anesthesia, you can enter the intubation mode in order to reduce
unnecessary alarms. To enter the intubation mode, follow this procedure:
1. Select the numeric area or waveform area of Paw, Flow or Vol to enter the RM menu.
2. Select Intubation Mode from the bottom of the menu.
For more information of the intubation mode, see 10.13Intubation Mode.
25.9 VCO
2
and Metabolic Monitoring
When the RM module is used together with the mainstream CO
2
module, the following parameters can be
monitored:
■ Volume CO
2
parameters (VCO
2
, MVCO
2
, FeCO
2
, SlopeCO
2
),
■ Ventilation parameters (Vtalv, MValv)
■ Dead space parameters (Vdaw, Vdaw/Vt, Vdalv, Vdalv/Vt, Vdphy, Vd/Vt).
When the RM module is used together with the sidestream CO
2
module or AG module configured with the
paramagnetic oxygen sensor, the following parameters can be monitored:
■ Volume CO
2
parameters (VCO
2
, MVCO
2
)
■ Oxygen consumption parameters (VO
2
, MVO
2
)
■ Respiratory Quotien (RQ) and Energy Expenditure (EE)
Monitoring above parameters is intended for adult and pediatric patients.
25.9.1 VCO
2
and Metabolic Parameters
The following table lists VCO
2
and metabolic parameters.
Parameter label Description Unit Required modules
VCO
2
CO
2
Production for one breath ml RM + mainstream CO
2
RM + sidestream CO
2
/AG
MVCO
2
CO
2
Minute Production ml/min
