2.3 System Components
The N22 and N19 monitors consist of the main unit, primary display, secondary displays, external modules,
satellite module rack (SMR), input devices, and output devices.
The N17, N15, N12, and N12C monitors consist of the main unit, external modules, satellite module rack (SMR),
input devices, and output devices.
• Your monitor may not include all these components. Contact your local service personnel for the
available components.
2.3.1 N22, N19 Main Unit
The main unit processes data from modules.
2.3.1.1 N22, N19 Main Unit for Integrated Installation
If the main unit and the primary display are installed together. It provides the following connectors:
N22, N19 Bottom View
• Main unit installation and debugging should be executed by Mindray service personnel or
authorized technicians.
(1) (2)
(3)
(4)
(5) (6) (7) (8) (9)
(10)
(11)
