17-3
When you are reviewing graphic trends, tabular trends or full-disclosure waveforms, the manual event symbol is
displayed at the time the event is triggered.
17.4.2 Reviewing Events
The monitor saves the events in real time. You can review these events.
In the [Review] menu, select [Events] to access the Events window.
The events that can be reviewed include parameter alarm events, arrhythmia alarm events and manual events. When an
event occurs, all the measurement numerics at the event trigger time and related waveforms 4 seconds, 8 seconds, or 16
seconds, as per the setting of recording length, respectively before and after the event trigger time are stored.
In this window:
You can view the desired events by selecting [Event].
You can view the desired events according to the level by selecting [Level].
After selecting the desired event, you can select [Details] to access the following window. In this window, the waveform
area displays the waveforms related to the event, and the parameter area displays the parameter values happened at the
event trigger time.
A total loss of power has no impact on the saved events.
1. Waveform area 2. Parameter area
In this window:
You can select or to navigate through the waveforms.
You can select or beside the [Event] button to switch between events.
You can set the desired [Gain] for ECG waveform.
You can set the desired [Sweep].
1
2
