E.8 Patient Auxiliary Current
Patient Auxiliary currents are measured between any selected Applied Part connector and the remaining Applied Part
connector s. All measurements may have a true RMS only response.
The following outlet conditions apply when performing the Patient Auxiliary Current test.
 normal polarity (Normal Condition)
 reverse polarity (Normal Condition)
 normal polarity with open neutral (Single Fault Condition)
 reverse polarity with open neutral (Single Fault Condition)
 normal polarity with open earth (Single Fault Condition)
 reverse polarity with open earth (Single Fault Condition)
LIMITS
 For CF applied parts,
 10μA in Normal Condition
 50μA in Single Fault Condition
 For BF applied parts,
 100μA in Normal Condition
 500μA in Single Fault Condition
NOTE
 Make sure the safety analyzer is authorized comply with requirement of IEC61010-1.
 Follow the instructions of the analyzer manufacturer.
