Mindray iMEC8 Vet User Manual

24-2
Cable Sets
3-Electrode Cable Sets
Type Compatible with Model Part No. Length Remark
Clip AHA
EL6303A 0010-30-42731 1m Long
EL6301A 0010-30-42726 0.6m /
EL6305A 0010-30-42896 1m Long
Snap AHA
EL6301B 0010-30-42734 1m Long
EL6311B 040-000146-00 1m Long
5-Electrode Cable Sets
Type Compatible with Model Part No. Length Remark
Clip AHA
EL6501A 0010-30-42727 0.6m /
EL6503A 0010-30-42729 1m to 1.4m Long
Snap AHA EL6501B 0010-30-42735
1.4m for RL and
LL; 1m for others
Long
24.2 SpO
2
Accessories
Extension Cable
Module type Remarks Part No.
Nellcor 8 pins 0010-20-42712
SpO
2
Sensors
The SpO
2
sensor material that patients or other staff will come into contact with has undertaken the bio-compatibility
test and is verified to be in compliance with ISO 10993-1.
Nellcor SpO
2
Module
Reusable VetSat(V-Sat) 1.1 m clip 9101-10-58134
 The extension cable must be used with the matching SpO
2
sensor.
 Wavelength emitted by the sensors intended for Nellcor SpO
2
module: red light: 660 nm, infrared light: 890 nm.
 The maximum photic output consumption of the sensor is less than 18 mW.
The information about the wavelength range and maximum photic output consumption can be especially useful to
clinicians, for example, clinicians performing photodynamic therapy.
