Mindray iPM-9800 - Front Housing Assembly (with Touchscreen)

6-6
6.3.3 Front Housing Assembly (with Touchscreen)
Exploded View
Parts List
SN P/N Description Qty
1 9211-20-87271-51 Front bezel 1
2 9211-20-87272 Alarm LED cover 1
3 9211-30-87306 Alarm LED board 1
4 6802-20-66892 Screen protection film 1
5 M04-051060--- Crosshead tapping screw PT2.0×8 2
6 6802-20-66696 Touchscreen strip 1 1
7 9211-20-87250 Front bezel overlay 1
8 6802-20-66697 Touchscreen strip 2 2
