Mindray M9 User Manual

3-14 System Installation
4. Press scan trigger button to receive barcode when ultrasound device is running (without
installing driving program). For more operation details, see relevant barcode reader manual.
 Disconnect the connecting cable
1. Using the tip of a screwdriver or some other tools with a sharp head, depress the cable’s
modular connector clip.
2. Carefully slide out the cable.
3.4.5.3 JADAK Barcode Reader
 Supported Barcode Reader Model
The Ultrasound System supports the following barcode readers: HS-1M JDK-2413 and HS-1R
JDK-2601.
 Operating System Version
If you need to use the JADAK barcode reader with the Ultrasound System, ensure that the
operating system version is as follows:
PC module (SOM5892-3517-M-8G) 2.0.11 or later versions
PC module (SOM-6897C3-T02A1E) 3.3.13 or later versions
If the version is lower than the requirements, upgrade the operating system.

Mindray M9 Specifications

General

Type	Portable Ultrasound System
Battery	Rechargeable lithium-ion battery
Battery Life	Up to 90 minutes
Display	15.6 inch high resolution LED monitor
Imaging Modes	B, M, Color, Power, PW, CW
Transducers	Linear, Convex, Phased Array
Transducer Ports	3
Probe Connectors	3
Connectivity	DICOM, USB, HDMI
Operating System	Windows-based
