7 Smart 3D
Operator’s Manual 7 - 3
7.1.3 Render Mode
Surface
Set 3D image rendering mode as Surface.
This is helpful for surface imaging, such as fetus face/hand or foot.
You may have to adjust the threshold to obtain a clear body boundary.
Max
Set Max as 3D image rendering mode, displays the maximum echo intensity in the observation
direction.
This is helpful for viewing bony structures.
Min
Set Min as 3D image rendering mode. Display the minimum echo intensity in the observation
direction.
This is helpful for viewing vessels and hollow structures.
X Ray
Set X-ray as 3D image rendering mode. Display the average value of all gray values in the ROI.
This is used for imaging tissues with different structure inside or tissues with tumor.
7.1.4 MPR
MPR represents three different views of 3D image.
In the quad display format view, the screen displays 3 MPRs (A, B and C) and the 3D image.
A, B, C sectional images are corresponding to the following sections of 3D image.
A window B window
C window 3D window (VR)
AB
C3D
