Mindray MX7 User Manual

16 Probes and Biopsy
Operator’s Manual 16 - 5
TIP:
For details of probe P7-3Ts/P8-3Ts, see the relevant Operator’s Manual.
16.1.1 Probe Functions by Part
The basic structures and corresponding functions of probes are basically the same; take the
following probe as an example.
P4-2s Body surface Abdomen,
Gynecology,
Obstetrics,
Cardiac, Pediatric,
Vasc ula r,
Thoracic/Pleural,
Cephalic
Supports TDI, Stress
Echo, Tissue
Tracking and contrast
imaging under
Cardiac exam mode.
P8-2s Body surface Abdomen,
Pediatric, Cardiac,
Cephalic
Supports TDI, Stress
Echo and Tissue
Tracking under
Cardiac exam mode.
P10-4s Body surface Abdomen,
Pediatric, Cardiac,
Nerve, Cephalic
Supports TDI, Stress
Echo and Tissue
Tracking under
Cardiac exam mode.
SP5-1Ns Body surface Abdomen,
Gynecology,
Obstetrics,
Cardiac, Pediatric,
Vasc ula r,
Thoracic/Pleural,
Cephalic
Supports TDI, Stress
Echo, Tissue
Tracking and contrast
imaging under
Cardiac exam mode.
P7-3Ts Transesophageal Cardiac Supports TDI and
Stress Echo.
P8-3Ts Transesophageal Cardiac Supports TDI and
Stress Echo.
Table 16-1 Available probes
Probe Mode Region Applied Intended Use Remark Probe Figure

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
