15 DICOM/HL7
Operator’s Manual 15 - 7
3. If there are several types of data on the media, the system will ask you to select the format.
Then, click [DICOMDIR].
15.7.3 Data Restore
Only system-accessible media can be selected.
After the DICOM format data are saved to external media, restore the data to the ultrasound system.
Connect the external media containing DCM files to the system.
1. In iStation, review the data stored on the external media.
2. Select the data to be restored in iStation.
3. Click [Restore Exam] on the iStation screen.
15.8 Structured Report
The Structured Report (SR) can be sent with meeting the following procedures:
• DICOM structured report installed with the corresponding exam mode;
• The state of the SR should be “Cancel” or “Stop”.
• Set the storage option to “Attach SR When Store Images” or “Only Store SR”, see
“4.7.2 DICOM Service Preset”.
Perform the following procedure:
1. Click to select a patient or an exam record in the list on iStation page, and click [Send Exam] in
the iStation page.
2. Select DICOM in the storage server list, select a server in the “Storage Server” list.
3. Click [OK], the status of sending task can be viewed in task management.
After successful storage of both image and structured report; you can see the storage
commitment mark “√” in the list below on the iStation screen.
Only the PACS system from the Medstreaming company (http://www.medstreaming.com/
default.aspx) supports sending self-defined measurements by DICOM SR.
