A Barcode Reader
Operator’s Manual A - 13
Reset the barcode reader
Perform the following procedure:
1. If the barcode reader is in malfunction, scan the following 1-D barcode to reset to default
settings.
2. Follow the configuration steps above to reconfigure the barcode reader.
A.3.4 HS-1R JDK-2601 Configuration
The barcode reader is configured through scanning the barcode. Ensure that the barcode reader is
properly connected to the Ultrasound System before scanning. After the barcode is successfully
scanned, the barcode reader buzzes, and the green indicator is On.
Configuration before use
Perform the following procedure:
1. Scan the following 1-D barcode to configure the barcode reader:
2. Scan the following 1-D barcode to enable the suffix:
Reset the barcode reader
Perform the following procedure:
1. If the barcode reader is in malfunction, scan the following 1-D barcode to reset to default
settings.
2. Follow the following steps to reconfigure the barcode reader:
For scanning Barcode
For scanning RFID

Mindray MX7 Specifications

General

Display Size	15.6 inches
Transducer Ports	3
Portability	Portable
Type	Ultrasound System
Display Type	LCD
Battery Life	120 min
Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler
Connectivity	Wi-Fi, Ethernet, USB
Applications	Vascular, Cardiology, OB/GYN, Urology
Probe Connectors	3
Operating System	Windows
